ZPE Systems Nodegrid Serial Console Plus

Serial Console Server

ZPE Systems Nodegrid Serial Console Plus
  • CechyCechy
  • PrezentacjaPrezentacja
  • Więcej informacjiWięcej informacji
  • PDFPDF
  • Strong Out-of-Band Management integration
  • Extensible applications with virtualization and containers
  • Zero-Touch Provisioning (ZTP) over the LAN and WAN for fast and easy setup in remote locations
  • Integration with the ZPE Cloud and Nodegrid Manager vendor-neutral, unified management solutions
  • Modern x86-64bit Linux Kernel for fast security patching and widespread software availability
  • Extended Automation based on actionable data
  • Failover to 5G/4G LTE and Wi-Fi
  • Gateway and multi-routing table capability
  • SSL VPN and Secure Tunnel
  • DHCP server for extra IPs for your remote site or to replace your current router altogether
  • Firewall is built-in and enabled with a checkbox
  • Secured with selectable encrypted cryptographic protocols, cipher suite levels, and configuration checksum™
  • Power control and monitoring provide alerts on IT device health and solve problems automatically
  • Orchestration via Puppet, Chef, Ansible, RESTful

Scale critical infrastructure with speed and reliability built-in

The Nodegrid Serial Console Plus (NSCP) helps scale your data center and critical remote infrastructure without management obstacles or downtime.

Connect 16, 32, 48, or 96 (Patent No. 9,905,980) serial devices and quickly scale to millions of nodes. Dual SFP+ and dual Ethernet ports keep data free from slowdowns, while the multi-core Intel CPU delivers blazing responsiveness. Built-in 5G/4G LTE and Wi-Fi options give you reliable cellular failover and secure out-of-band access, so you can keep it all online all the time.

Nodegrid Serial Console Plus gives you high-density, Gen 3 out-of-band (OOB) connectivity in a 1U box. With the vendor-neutral NSCP, you can scale fast and manage diverse infrastructures through a single point of control, whether at the data center or colocation hub. NSCP also gives you built-in reliability via 5G/4G LTE and Wi-Fi capabilities, so you don't have to shop around for additional failover or out-of-band solutions.

Simple & Fast

No more waiting! The Nodegrid Serial Console device is easy to deploy and configure. Its lightning-fast, multi-core x86-64 CPU, large memory, SSD, and Linux-based Nodegrid OS can handle 1,000+ concurrent sessions, allowing for more operations, users, and I/O than any other console server.



Secure & Sustainable

The NSCP keeps your information secure by blending existing policy-based enterprise AD/LDAP/SAML authentication and authorization with the latest in cryptographic protocols and cipher suite levels, threat prevention, up-to-date SSL and SSH data encryption, IP filtering, secure boot, self-encrypted disk, TPM, and a system configuration checksum.



Reliable & Scalable

Nodegrid is deployed by the biggest tech and financial companies in the world. It was designed by award-winning console industry veterans and built using reliable, open, and modular industry-standard hardware components.




Benefits

  • Reduces CAPEX and OPEX expenses with a consolidated, extensible solution and automated management
  • Minimizes MTTR, downtime, and trips to the data center with secure, centralized, instant remote device access and control.
  • Increases site reliability with open, industry-standard hardware and easy-to-use software
  • Supports fast, cost-efficient scaling with automated deployments, even in mixed environments



ProdGrafik

Technical Specifications


Connectivity • Dual SFP+ Ethernet ports & Gigabit Ethernet ports
• Dual SIM LTE, Console Port, Wi-Fi
• 2X SFP+ Ethernet ports
• 2X Gigabit Ethernet ports
• Multiple Routing Tables
• Failover to 5G/4G/LTE modem
Managed Power Devices Vendor-neutral PDU support
Managed IPMI Devices OpenBMC, HP iLO, Dell iDRAC, Supermicro/Quanta IPMI, IPMI 2.0 compatible devices, Cisco CIMC/UCS, IBM IMM, Oracle ILOM, EMC/NetApp Storage IPMI
Sensors Support for a wide range of USB sensors
Networking • IPv4 / IPv6 Support
• VLAN, Layer 3 Routing, BGP, OSFP, RIP, QoS, DHCP (Client & Server)
Port Access • Direct access by port name, TCP port, device name & IPv4/IPv6
• High performance port login: <1 sec on SSH, <3 sec on Telnet
• 1000+ simultaneous sessions
• Port sharing
• Command Line Interface (CLI)
• Port custom field support, port icon configuration, port search
• Device clustering across multiple Nodegrid units
• Break-over SSH support
System Management • Extensible, automated control based on actionable real-time data
• Web GUI management portal, web console, Command Line Interface (CLI), Linux root shell, SNMP, RESTful API
• Zero Touch Provisioning (ZTP) via LAN/DHCP, WAN/ZPE Cloud, USB for configuration & firmware updates
• Multiple & customizable user levels of access
• Auto-discovery via network scan & custom probes
• SNMPv1,v2 & SNMPv3-v1 IPv4/IPv6 with MD5, SHA-224, SHA-256, SHA-384, SHA-512, DES, AES-192, AES-256
• Orchestration Integration & Automation: Puppet, Chef, Ansible, RESTful, ZPE Cloud & Nodegrid Clustering Feature
• File sharing via FTP, NFS, SSHFS, Windows Sharing, web file browser, ZPE Cloud
• Remote Procedure Call (RPC, gRPC)
• NetFlow, LLDP
Access Protocols HTTPS, SSHv2; (Optional) HTTP, Telnet & SSHv1
Device View Options Tree, Table, Geo Map, Node, & WEB Interface with search
Data Logging & Notifications • Local port buffering: 20 MB per port
• Local, NFS, syslog, off-line data logging
• Time stamp & rotation for data logging
• Event destination: email, syslog, local, syslog, email, ZPE Cloud, Splunk & more
• Notification: syslog, email, ZPE Cloud, Splunk & more
Operating System Built-in x86_64bit Nodegrid OS
Warranty 2-Year Limited Warranty
Security • Hardened device with BIOS protection, TPM 2.0, UEFI Secure Boot, Signed OS, Self-Encrypted Disk (SED), Geofencing
• X.509 SSH certificate support, 4096-bit encryption keys
• Selectable cryptographic protocols for SSH & HTTPS (TLSv1.3,TLSv1.2, TLSv1.1, TLSv1)
• Selectable cypher suite levels: high, medium, low, custom
• IPsec, WireGuard, OpenSSL VPN with support for multi sites
• Local, AD/LDAP, RADIUS, TACACS+, Kerberos, authentication
• SAML 2.0 support via Duo, Okta, Ping Identity, ADFS
• Two-Factor Authentication with RSA & DUO
• Local, backup-user authentication support
• User-access lists per port
• Group/Role-Based Authorization: AD/LDAP, RADIUS, TACACS+
• Fine grain & role-based access control
• Firewall: IP packet & security filtering, IP forwarding support
• MD5 / SHA System Configuration Checksum™
• System event logging to file, syslog, email, ZPE Cloud, Splunk & more
• Custom security settings
• Strong password enforcement
Power Specifications • 40V-63 VDC dual power input (redundant)
• Single or Dual AC: 100-240 VAC, 50/60 Hz
• Power consumption 45 W typical
CPU & Storage (Upgrades Available) • Intel x86_64 Quad-cores
• 4GB of DDR4 DRAM
• 32GB FLASH (mSATA SSD)
Interfaces • 16, 32, 48, 96 RS-232 serial ports on RJ45 @ 230,400 bps max/port
• 1X RS-232 serial console port on RJ45
• 2X USB 3.0 Host on Type A connector
• 2X SFP+ 1/2.5/10GB & 2 Gigabit (10/100/1000BT)
Ethernet interfaces on RJ45
• 1X HDMI output port
• 1X 5G/4G/LTE Radio
• 1X Wi-Fi (Optional)
• 2X Dual SIM (Optional)
Physical • Front-Rear Mounting Brackets
• Size (L X W X H): 443 X 312 X 43 mm (17.4 X 12.3 X 1.7 in), 1U
• Weight: 5.265 kg (11.6 lb), depending on options
• Shipping Weight: 8.745 kg (19.3 lb)
• Shipping (L X W X H): 533 X 497 X 209 mm (21 X 19.6 X 8.3 in)
Environmental • Operation: 0 to 60° C (32şF to 140° F), 5-95% RH, non-cond.
• Storage: -20 to 67° C (-4şF to 153° F), 5-95% RH, non-cond.




Ordering Informationn


SKU Description
Available 16 Port Configurations
ZPE-NSCP-T16R-STND-SAC ZPE Nodegrid Serial Console Plus. 16-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console
ZPE-NSCP-T16R-STND-DAC ZPE Nodegrid Serial Console Plus. 16-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console
ZPE-NSCP-T16R-STND-DDC ZPE Nodegrid Serial Console Plus. 16-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console
ZPE-NSCP-T16R-STND-SAC-W5 ZPE Nodegrid Serial Console Plus. 16-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console. Wi-Fi 5 (2X2 Dual Stream)
ZPE-NSCP-T16R-STND-DAC-W5 ZPE Nodegrid Serial Console Plus. 16-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console. Wi-Fi 5 (2X2 Dual Stream)
ZPE-NSCP-T16R-STND-DDC-W5 ZPE Nodegrid Serial Console Plus. 16-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console. Wi-Fi 5 (2X2 Dual Stream)
ZPE-NSCP-T16R-STND-SAC-4G ZPE Nodegrid Serial Console Plus 16-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, 4G/LTE (CAT 12)
ZPE-NSCP-T16R-STND-DAC-4G ZPE Nodegrid Serial Console Plus 16-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, 4G/LTE (CAT 12)
ZPE-NSCP-T16R-STND-DDC-4G ZPE Nodegrid Serial Console Plus 16-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, 4G/LTE (CAT 12)
ZPE-NSCP-T16R-STND-SAC-W5-4G ZPE Nodegrid Serial Console Plus 16-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, Wi-Fi 5 (2X2 dual stream) & 4G/LTE (CAT 12)
ZPE-NSCP-T16R-STND-DAC-W5-4G ZPE Nodegrid Serial Console Plus 16-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, Wi-Fi 5 (2X2 dual stream) & 4G/LTE (CAT 12)
ZPE-NSCP-T16R-STND-DDC-W5-4G ZPE Nodegrid Serial Console Plus 16-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, Wi-Fi 5 (2X2 dual stream) & 4G/LTE (CAT 12)
ZPE-NSCP-T16R-STND-SAC-5G ZPE Nodegrid Serial Console Plus. 16x RJ45 Serial rolled, 2x GbE, 2x SFP+, 4-Core CPU, 4GB DDR4, 32GB SLC, 2x USB 3.0, WiFi 5, 5G LTE (CAT12). Single AC, cord included. Includes Standard 2 year support and HW warranty.
ZPE-NSCP-T16R-STND-DAC-5G ZPE Nodegrid Serial Console Plus. 16x RJ45 Serial rolled, 2x GbE, 2x SFP+, 4-Core CPU, 4GB DDR4, 32GB SLC, 2x USB 3.0, WiFi 5, 5G LTE (CAT12). Dual AC, cord included. Includes Standard 2 year support and HW warranty.
ZPE-NSCP-T16R-STND-DDC-5G ZPE Nodegrid Serial Console Plus. 16x RJ45 Serial rolled, 2x GbE, 2x SFP+, 4-Core CPU, 4GB DDR4, 32GB SLC, 2x USB 3.0, WiFi 5, 5G LTE (CAT12). Dual DC, cord not included. Includes Standard 2 year support and HW warranty.
Available 32 Ports Configurations
ZPE-NSCP-T32R-STND-SAC ZPE Nodegrid Serial Console Plus. 32-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console
ZPE-NSCP-T32R-STND-DAC ZPE Nodegrid Serial Console Plus. 32-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console
ZPE-NSCP-T32R-STND-DDC ZPE Nodegrid Serial Console Plus. 32-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console
ZPE-NSCP-T32R-STND-SAC-W5 ZPE Nodegrid Serial Console Plus. 32-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console. Wi-Fi 5 (2X2 Dual Stream)
ZPE-NSCP-T32R-STND-DAC-W5 ZPE Nodegrid Serial Console Plus. 32-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console. Wi-Fi 5 (2X2 Dual Stream)
ZPE-NSCP-T32R-STND-DDC-W5 ZPE Nodegrid Serial Console Plus. 32-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console. Wi-Fi 5 (2X2 Dual Stream)
ZPE-NSCP-T32R-STND-SAC-4G ZPE Nodegrid Serial Console Plus 32-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, 4G/LTE (CAT 12)
ZPE-NSCP-T32R-STND-DAC-4G ZPE Nodegrid Serial Console Plus 32-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, 4G/LTE (CAT 12)
ZPE-NSCP-T32R-STND-DDC-4G ZPE Nodegrid Serial Console Plus 32-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, 4G/LTE (CAT 12)
ZPE-NSCP-T32R-STND-SAC-W5-4G ZPE Nodegrid Serial Console Plus 32-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, Wi-Fi 5 (2X2 dual stream) & 4G/LTE (CAT 12)
ZPE-NSCP-T32R-STND-DAC-W5-4G ZPE Nodegrid Serial Console Plus 32-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, Wi-Fi 5 (2X2 dual stream) & 4G/LTE (CAT 12)
ZPE-NSCP-T32R-STND-DDC-W5-4G ZPE Nodegrid Serial Console Plus 32-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, Wi-Fi 5 (2X2 dual stream) & 4G/LTE (CAT 12)
ZPE-NSCP-T32R-STND-SAC-5G ZPE Nodegrid Serial Console Plus. 32x RJ45 Serial rolled, 2x GbE, 2x SFP+, 4-Core CPU, 4GB DDR4, 32GB SLC, 2x USB 3.0, WiFi 5, 5G LTE (CAT12). Single AC, cord included. Includes Standard 2 year support and HW warranty.
ZPE-NSCP-T32R-STND-DAC-5G ZPE Nodegrid Serial Console Plus. 32x RJ45 Serial rolled, 2x GbE, 2x SFP+, 4-Core CPU, 4GB DDR4, 32GB SLC, 2x USB 3.0, WiFi 5, 5G LTE (CAT12). Dual AC, cord included. Includes Standard 2 year support and HW warranty.
ZPE-NSCP-T32R-STND-DDC-5G ZPE Nodegrid Serial Console Plus. 32x RJ45 Serial rolled, 2x GbE, 2x SFP+, 4-Core CPU, 4GB DDR4, 32GB SLC, 2x USB 3.0, WiFi 5, 5G LTE (CAT12). Dual DC, cord not included. Includes Standard 2 year support and HW warranty.
Available 48 Ports Configurations
ZPE-NSCP-T48R-STND-SAC ZPE Nodegrid Serial Console Plus. 48-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console
ZPE-NSCP-T48R-STND-DAC ZPE Nodegrid Serial Console Plus. 48-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console
ZPE-NSCP-T48R-STND-DDC ZPE Nodegrid Serial Console Plus. 48-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console
ZPE-NSCP-T48R-STND-SAC-W5 ZPE Nodegrid Serial Console Plus. 48-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console. Wi-Fi 5 (2X2 Dual Stream)
ZPE-NSCP-T48R-STND-DAC-W5 ZPE Nodegrid Serial Console Plus. 48-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console. Wi-Fi 5 (2X2 Dual Stream)
ZPE-NSCP-T48R-STND-DDC-W5 ZPE Nodegrid Serial Console Plus. 48-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console. Wi-Fi 5 (2X2 Dual Stream)
ZPE-NSCP-T48R-STND-SAC-4G ZPE Nodegrid Serial Console Plus 48-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, 4G/LTE (CAT 12)
ZPE-NSCP-T48R-STND-DAC-4G ZPE Nodegrid Serial Console Plus 48-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, 4G/LTE (CAT 12)
ZPE-NSCP-T48R-STND-DDC-4G ZPE Nodegrid Serial Console Plus 48-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, 4G/LTE (CAT 12)
ZPE-NSCP-T48R-STND-SAC-W5-4G ZPE Nodegrid Serial Console Plus 48-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, Wi-Fi 5 (2X2 dual stream) & 4G/LTE (CAT 12)
ZPE-NSCP-T48R-STND-DAC-W5-4G ZPE Nodegrid Serial Console Plus 48-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, Wi-Fi 5 (2X2 dual stream) & 4G/LTE (CAT 12)
ZPE-NSCP-T48R-STND-DDC-W5-4G ZPE Nodegrid Serial Console Plus 48-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, Wi-Fi 5 (2X2 dual stream) & 4G/LTE (CAT 12)
ZPE-NSCP-T48R-STND-SAC-5G ZPE Nodegrid Serial Console Plus. 48x RJ45 Serial rolled, 2x GbE, 2x SFP+, 4-Core CPU, 4GB DDR4, 32GB SLC, 2x USB 3.0, WiFi 5, 5G LTE (CAT12). Single AC, cord included. Includes Standard 2 year support and HW warranty.
ZPE-NSCP-T48R-STND-DAC-5G ZPE Nodegrid Serial Console Plus. 48x RJ45 Serial rolled, 2x GbE, 2x SFP+, 4-Core CPU, 4GB DDR4, 32GB SLC, 2x USB 3.0, WiFi 5, 5G LTE (CAT12). Dual AC, cord included. Includes Standard 2 year support and HW warranty.
ZPE-NSCP-T48R-STND-DDC-5G ZPE Nodegrid Serial Console Plus. 48x RJ45 Serial rolled, 2x GbE, 2x SFP+, 4-Core CPU, 4GB DDR4, 32GB SLC, 2x USB 3.0, WiFi 5, 5G LTE (CAT12). Dual DC, cord not included. Includes Standard 2 year support and HW warranty.
Available 96 Ports Configurations
ZPE-NSCP-T96R-STND-SAC ZPE Nodegrid Serial Console Plus. 96-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console
ZPE-NSCP-T96R-STND-DAC ZPE Nodegrid Serial Console Plus. 96-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console
ZPE-NSCP-T96R-STND-DDC ZPE Nodegrid Serial Console Plus. 96-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console
ZPE-NSCP-T96R-STND-SAC-W5 ZPE Nodegrid Serial Console Plus. 96-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console. Wi-Fi 5 (2X2 Dual Stream)
ZPE-NSCP-T96R-STND-DAC-W5 ZPE Nodegrid Serial Console Plus. 96-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console. Wi-Fi 5 (2X2 Dual Stream)
ZPE-NSCP-T96R-STND-DDC-W5 ZPE Nodegrid Serial Console Plus. 96-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console. Wi-Fi 5 (2X2 Dual Stream)
ZPE-NSCP-T96R-STND-SAC-4G ZPE Nodegrid Serial Console Plus 96-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, 4G/LTE (CAT 12)
ZPE-NSCP-T96R-STND-DAC-4G ZPE Nodegrid Serial Console Plus 96-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, 4G/LTE (CAT 12)
ZPE-NSCP-T96R-STND-DDC-4G ZPE Nodegrid Serial Console Plus 96-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, 4G/LTE (CAT 12)
ZPE-NSCP-T96R-STND-SAC-W5-4G ZPE Nodegrid Serial Console Plus 96-port Cisco Rolled, Single AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, Wi-Fi 5 (2X2 dual stream) & 4G/LTE (CAT 12)
ZPE-NSCP-T96R-STND-DAC-W5-4G ZPE Nodegrid Serial Console Plus 96-port Cisco Rolled, Dual AC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, Wi-Fi 5 (2X2 dual stream) & 4G/LTE (CAT 12)
ZPE-NSCP-T96R-STND-DDC-W5-4G ZPE Nodegrid Serial Console Plus 96-port Cisco Rolled, Dual DC, 4-Core Intel CPU, 4GB DDR4, 32GB SSD, 2 SFP+, 2 GbE, 2 USB 3.0, 1 HDMI, 1 console, Wi-Fi 5 (2X2 dual stream) & 4G/LTE (CAT 12
